CONPRINTA IMD

Competitive advantage with PrePrint Volume on Demand

You know your customers, their needs, and their objectives better than anyone else. Our CONPRINTA IMD system was developed as a flexographic system for producing preprint corrugated products that not only meet but exceed the expectations of your customers. Whether you need transport packaging or POS products, our IMD system lets you offer your customers the greatest variety, flexibility, and print quality in the high-graphic range.

Our reliable, patented belt technology also guarantees optimal productivity, with short throughput times and minimal to no setup time. You can fill your orders on demand. Line stoppage? Setup waste? Expensive printing inks? Not with our IMD machines. Take advantage of industry-leading uptime, fast implementation of new print orders even during production, and low-cost, environmentally friendly water-based inks. CONPRINTA machines can be expanded modularly up to 12 units.

Our IMD machines are currently available in multiple widths and can be produced according to your requirements.

Contact

Man in the corridor.

Leonard Duerr

+49 . 5551 . 91000-12

IMD complete machines

    IMD
Working Width [mm]   1100 - 2800
Repeat Length, min. [mm]   965
Repeat Length, max. [mm]   4550
Print Registration [mm]   +/-0,1
Incremental belt steps 6,35 mm (0.25 inch)
Paper Range [gsm /m2] 80 - 400
Line Screen /
Print Resolution, max.  [lpi]
60 lpc (150 lpi)
Customer Plate Options elastomer or photopolymer
Ink / Varnish water-based and sensor-based
Mechanical Speed,
max.  [m/min.]
450
Drying system Infrared or hybrid (gas-, steam- or electrical powered), closed
loop hot air recovery system
Rewinder nonstop turret winder  with or withour winding shaft
Unwinder shaftless unwinding with splice unit
Register control camera-based
Inline Inspection 100 % web inspection, high resolution traversing camera
Options inline spectral photometer, job data base, UV dryer, preconditioner, seamless varnish-/ tinting unit, defect flagging device
Accessories paperhandlingsystems, plate mounting equipment
Consumables beltmaterial on reel or as sheet
